Technical Reference · Bending
Rebar Bend Diameter Guide
A minimum bend diameter is not a property of rebar. It is fixed by two authorities that can disagree: the bar material standard, which sets the bend the bar must withstand without cracking as a condition of its designation, and the design or detailing code adopted by the project, which sets the bend radius the concrete and the bar forces require. A fabricator works to whichever is more demanding — and neither can be inferred from the diameter alone.
This page will not give you a bend diameter. No ratio, no multiple of bar size, no chart. A bend requirement comes from two documents — the bar standard and the project's detailing authority — and a number quoted without them is how a bar cracks in the machine.
Information current as of
What Governs a Bend
Two authorities fix a bend — and they answer different questions
Most confusion about bend diameters comes from treating them as one requirement. They are two. The bar standard asks whether the material survives being bent. The design and detailing authority asks whether that bend radius is right for the structure. A shape has to satisfy both, and one can be more demanding than the other.
Gate 1 — The bar material standard
Authority
The reinforcement standard the bar is supplied to
The question it answers
Can the bar be bent to this diameter without the material failing?
What it needs
- The reinforcement standard and grade designation, with edition
- The bar diameter and whether it is the bar's nominal size
- Whether the bend is to be executed on the supplied bar and in what condition
What makes it invalid: A bend diameter taken from one grade or one standard and applied to another. Bend requirements differ between designations and between editions of the same standard; the bend test the material was qualified against does not transfer.
Gate 2 — The design and detailing authority
Authority
The design code and project detailing rules
The question it answers
Is this bend radius adequate for the structural and concrete demands at that location?
What it needs
- The design code and detailing rules adopted by the project, with edition
- The element, and the cover and crack-control requirements at the bend
- Whether the bar is bent around another bar, and the geometry of the cage there
What makes it invalid: Satisfying the material standard and stopping. A bar can be perfectly bendable and still be bent too tightly for the cover, the concrete or the bar forces at that point — the two gates answer different questions.
At the bending machine the two gates meet. The former selected has to suit the bar being fed into it, and the geometry it produces has to match the detail that was approved — a mismatch either way is discovered as a cracked bar or a rejected cage.
Why no ratio can be published
Bend requirements are expressed differently by different authorities — sometimes relative to the bar's own diameter, sometimes as an absolute radius, sometimes with additional provisions triggered by size, grade or the condition of the bend. They are also revised between editions, and a bend rule that changed between editions is a different document rather than a clarification.
That means a ratio which happens to be correct under one authority, for one grade, at one diameter, is not a benchmark for another. Publishing it as a general figure is how a fabricator sets the wrong former and finds out at inspection.
Bend Requirement Validation
Check both gates before the schedule is issued
This check separates the bar specification from the design and detailing approval, because they belong to different people and fail in different ways. It reports whether each gate is satisfied — and under no combination of answers does it state a bend diameter.
Gate 1 — bar specification
Gate 2 — design and detailing approval
Nothing is submitted. Clear the form at any time.
What this check will never do
- It will not output a bend diameter, a mandrel size or a multiple of the bar diameter.
- It will not assume a hot-bending, cold-bending or re-bending condition — that is an input you state, not a default it applies.
- It will not treat the bar standard as covering the design requirement, or the reverse.
- It will not approve a bend — it reports whether the two authorities behind one have been identified.
Not enough information to assess this bend
This check establishes whether both authorities that govern a bend diameter have been identified. It does not produce a bend value. Answer every input above, or the assessment has nothing to work from.
Fabricator record
A blank record for the two authorities behind a bend requirement, so a checking engineer can see what the bar was bent against. The value line is intentionally empty.
Rebar bend requirement — fabricator record Bar material standard: Select the bar material standard… Design / detailing authority: Select the design / detailing authority… Bending condition: How is the bend to be executed? Grade designation (by bar mark): Bar diameter (by bar mark): Shape code and bend geometry: Required bend / mandrel diameter: Bending machine and former size used: Checked by (fabricator) and date: Accepted by (design authority): Not a design output. This record captures the two authorities behind a bend requirement; the value itself comes from the standards and detailing rules named above.
When It Settles
The two gates close at different points in the programme
A fabricator needs the bend geometry before a bar is bent; the design authority has to have fixed it before the schedule is issued. Understanding which gate closes when tells you what can go to the bending machine today and what has to wait — and which question belongs to whom.
Named before the schedule is issued
The two governing documents
- The bar material standard and grade designation, with edition
- The project's design and detailing authority, with edition
- The shape code system the schedule will be drawn in
These are documentary. They should be settled on day one, and every later disagreement traces back to one of them being left open.
Fixed as each detail is drawn
The geometry itself
- Bend geometry at each location, including hooks and links
- Cover and crack-control constraints at the bend
- Whether the bar bends around another bar at that point
This is where the two gates interact. A radius that satisfies the bar may still not satisfy the cover — the more demanding of the two governs.
Confirmed at the bending machine
Execution
- The former actually fitted to the machine for that size
- Whether any bar is heated, straightened or re-bent
- Inspection of the bent bar against the drawn shape
Nothing upstream can be checked once the bar is bent. If the condition or the former is wrong, it is found here or not at all.
Bending conditions are not interchangeable
Bending a bar at ambient temperature, heating it first, and straightening one that has already been bent are three different operations with three different consequences for the material. Some standards restrict or prohibit particular combinations, and a bar that has been heated or re-bent is no longer the bar that was certified unless the procedure was specified and agreed.
This is why the check above asks you to state the condition rather than assume one. A bend requirement read for a cold-bent bar is not a requirement for a heated bend, and the difference is not visible in the finished shape.
Recording It
What travels with a bent bar, and what stays with the designer
A fabricator bending to a schedule needs the geometry and the bar; the checking engineer needs to see what the geometry was derived from. Separating those two keeps the enquiry clean and makes the review possible.
Belongs on the enquiry
- Element and drawing reference
- So each shape can be traced to the detail it serves.
- Standard, grade and diameter
- The bar being bent, stated as the drawings name it.
- Shape codes and bend geometry
- The drawn shapes. The bend requirement is already expressed in the schedule, not derived by the fabricator.
- Quantity per shape and total
- The basis for price and for the bending workload.
- Delivery sequence
- Which pours each delivery serves, so bent sets arrive together.
- Inspection and documentation
- Whether the bent shapes are inspected at the yard, and what certificate set is required.
Does not belong on the enquiry
Each of these is a design or detailing decision. A supplier who answers one is supplying an opinion that carries no responsibility for the structure — and it will be relied upon.
- "What bend diameter applies to this bar?"
- The requirement comes from the bar standard and the project's detailing authority. A supplier's figure cannot substitute for either document.
- "Can we bend it tighter to fit?"
- Tightening a bend is a change to the detail. It goes back through the detailer and the design authority, never to the machine.
- "Can we heat it to bend it?"
- Heating changes the material condition and is a specified procedure. It is not a workshop choice.
- "Can you straighten this one and re-bend it?"
- Re-bending is restricted by most bar standards and needs the design authority's agreement before it is attempted.
Technical reference
Two families of document sit behind a bend. The reinforcement material standard — BS 4449, ASTM A615/A615M, ASTM A706/A706M and EN 10080 among those commonly specified in the region — sets grade designations, mechanical properties including bend-test requirements, rib geometry and the test regime, and its editions are revised independently. The design and detailing authority — a design code such as ACI 318 or EN 1992, together with the schedule standard used to convey shapes, such as BS 8666 — sets the bend and hook geometry required for structural and concrete reasons.
The two are related but distinct, and neither substitutes for the other. Confirm both, with editions, before any bend geometry is fixed — and note that ASTM A706 is a low-alloy designation with its own provisions, so it should not be treated as equivalent to a carbon-steel grade of the same nominal strength.
Bars and grades commonly specified in GCC bend schedules
Bend requirements are set per grade and per diameter, so the designation on the schedule matters before any geometry is applied to it.
