Hollow Section Dimensions Chart
Use this hollow section dimensions chart as a verified reference to build an RFQ line, not as proof of stock or final design compliance. Filter by shape and standard, disclose units/method, and separate theoretical/reference values from supplier-certified shipment data.
- Shape & standard
- Unit / dimension method
- Wall & tolerance basis
- Theoretical vs certified
- Verify before RFQ
Price on request · theoretical/reference values are separated from supplier-certified stock and shipment data; verify wall, grade/material, finish and design compliance separately
Working technical tool
Hollow Section Dimension Filter
A reference filter that turns a hollow-section shape, standard family, unit system and dimension into a verified reference row and a copyable RFQ line. It never invents a complete size table: it validates the inputs, echoes only verified fields, and puts a publication blocker on any value that cannot be sourced to the governing standard, project specification or mill certificate.
Result
Shape and governing standard required
A hollow-section dimension is only meaningful with a stated shape and a stated standard family and edition — for example EN 10219 (cold formed), EN 10210 (hot finished), or the ASTM A500/A1085 route. Select both so the chart identifies the reference the value answers to. Dimensional values alone do not establish wall, grade, material, finish or final design compliance.
Governing standard & edition
Every dimension is a reference value under a stated standard family and edition — EN 10219 (cold formed), EN 10210 (hot finished), or the ASTM A500/A1085 route. The chart names its source; it never invents a value.
Unit system coherence
Outside dimensions, wall and length are kept under one unit system — metric (mm) or imperial (in) — converted consistently so no false precision is created between shape, wall and length.
Theoretical vs certified
Reference values are separated from actual stock, price, lead time and certified shipment data. Unit weight implied by a cross-section is theoretical until confirmed against the MTC and shipping records.
Publication blocker
A specific numeric section-property value is published only when the current standard, the project specification or a verified mill/MTC value supports it. Otherwise the cell is blocked, never filled with an estimate.
Method, formula & data conditions
How the reference values are derived, and where they stop
This chart is a reference that states its method, unit system, source hierarchy, edition/date, assumptions, applicability and limitations. It separates theoretical/reference results from supplier-certified values and blocks the publication of any value without a source.
Method
- Reference dimensions keyed to a stated standard family and edition — never an anonymous chart.
- One coherent unit system (metric mm or imperial in) across outside dimension, wall and length.
- Unit weight implied by a cross-section is theoretical until confirmed against the MTC and shipping records.
Source hierarchy & limitations
- Governing current licensed standard and edition first; project specification second; verified mill/MTC value third.
- EN 10219 and EN 10210 are not interchangeable; source square/rectangular sectional properties are not equivalent.
- Reference dimension is not stock, grade, finish, wall-standard table or final design compliance.
Data conditions
A reference row is published only when the shape, standard and unit system are stated. A numeric wall thickness, radius, corner detail, unit weight or section-property figure is blocked unless the current standard, the project specification or a verified mill/MTC value supports it. This boundary is what keeps the chart a decision aid rather than a source of invented values.
Procurement-grade worked examples
From a dimension to an RFQ line, without inventing a figure
Each example is a clearly labelled hypothetical input that shows how to turn a hollow-section dimension into a complete RFQ line. None of these reflect stock or a company project; each teaches the input-to-RFQ method.
Hypothetical example
SHS 100 × 100 × 4 mm
Input: Rectangular/square support member; outside 100 × 100 mm, wall 4 mm, length 6000 mm, metric.
RFQ line: Hollow section, SHS 100 × 100 × 4 mm × 6000 mm, EN 10219 (edition to be confirmed), unit metric; tolerance per the standard edition — wall-standard table, grade, finish and stock verified before RFQ.
Shows the exact shape, outside dimensions × wall × length, standard and unit in one RFQ line so no inferred diameter or wall slips in.
Hypothetical example
RHS 200 × 100 × 8 mm
Input: Rectangular beam with directional stiffness; 200 × 100 mm, wall 8 mm, length 8000 mm, metric.
RFQ line: Hollow section, RHS 200 × 100 × 8 mm × 8000 mm, per governing project specification (edition to be confirmed), unit metric; section-property field (e.g. Iy) verified against a current source before use.
Shows how an axial (Iy) vs transverse section-property distinction must be verified before a value is read off a reference.
Hypothetical example
CHS round tube
Input: Round hollow section for a support post; outside diameter to be confirmed against standard, wall to be confirmed, imperial.
RFQ line: Hollow section, round (CHS), ASTM A1085 series (edition to be confirmed), outside and wall to be confirmed in imperial; dimensions only — grade, mechanical basis, finish and stock verified separately.
Shows the case where the dimension is not yet fixed: the RFQ carries the standard and the “to be confirmed” fields rather than an invented diameter.
Standards & size context
A decision-grade specification on the reference, with its evidence warning
The governing standard family/edition and the project specification fix the scope, tolerances, dimensions, sectional properties and ordering requirements for the hollow section. Every row carries an explicit evidence warning — the publication of unsourced numeric values is blocked.
| Reference field | Method / unit | Source | Condition / evidence warning | RFQ action |
|---|---|---|---|---|
| Shape & outside dimension | Stated shape (SHS / RHS / CHS) and outside (side) dimension under one unit system | Reference chart keyed to standard family/edition | A reference value, not stock, grade, finish or design compliance | State shape, outside dimension, wall, length, unit and standard |
| Wall / thickness | Wall per the standard's wall table (blocked unless sourced) | Current standard/edition or project specification | Publication blocked without a current source or verified MTC value | Carry the wall and tolerance basis explicitly |
| Radius / corner detail | Per the standard family — cold formed vs hot finished differ | Current standard/edition | Not interchangeable between EN 10219 and EN 10210 | Confirm the radius/corner against the route and edition |
| Unit weight (reference) | Theoretical per cross-section; actual weight is supplier-certified | Reference derivation — not a shipping weight | Theoretical reference only; actual weight from MTC and shipping records | Request actual weight declaration with the MTC |
| Section-property field (Ix, ry, etc.) | Per the governing standard's sectional-property tables | Current standard/edition or project spec | Verify the value against the governing edition; source square/rectangular properties are not equivalent across EN 10219/10210 | Verify the property source before use |
| Tolerance & dimensional inspection | Tolerance per the stated standard/edition | Current standard/edition + dimensional record | Dimensional record requested, never implied | Request the dimensional/gauge record with the MTC |
These tables are decision aids and carry no inventory value. Any gauge, weight, dimension, tolerance, radius or section-property figure is confirmed against the governing standard/edition, the project specification and the mill certificate before quotation. Price on request.
